Ethernet Switch Comparison
| KBC Model | Download | RJ45-GB | SFP-GB | SFP-10G | Ports Total | PoE Budget (watts) |
|---|---|---|---|---|---|---|
| ESMGS4-P2-B | Specification | 4 | 2 | - | 6 | 120 up to 30 watts max per RJ45 port |
| ESMGS8-C2-B | Specification | 10 | 2 (shared) | - | 10 | 240 up to 30 watts max per RJ45 port |
| ESMGS8-P2-L-B | Specification | 8 | 2 | - | 10 | 90 @ 12 VDC 160 @ 24 VDC 180 @ 36 VDC up to 30 watts max per RJ45 port |
| ESMGH8-P2-B | Specification | 8 | 2 | - | 10 | 500W up to 90W per port x 4 ports and 30W per port x 4 ports |
| ESMGS16-P2-RX | Specification | 16 | 2(shared) | - | 16 | 480 up to 30 watts max per RJ45 port |
| ESMGS24-P4-RXS | Specification | 24 | 4(shared) | - | 24 | 360 up to 30 watts max per RJ45 port |
| ESMGS24-P4-RX | Specification | 24 | 4(shared) | - | 24 | 720 up to 30 watts max per RJ45 port |
| ESMGS24-P4-RXN-B | Specification | 24 | 4 | - | 24 | 480 up to 30 watts max per RJ45 port |
| ESMGS24-N4-RXN-B | Specification | 24 | - | 4 | 28 | 470 up to 30 watts max per RJ45 port |
| KBC Model | Download | RJ45-GB | SFP-GB | SFP-10G | Ports Total |
|---|---|---|---|---|---|
| ESMGN4-P2-B | Specification | 4 | 2 | - | 6 |
| ESMGN8-C2-B | Specification | 10 | 2 (shared) | - | 10 |
| ESMPN8-N2-B | Specification | - | 8 | 2 | 10 |
| ESMGN8-P4-B | Specification | 8 | 4 | - | 12 |
| ESMPN24-C4-RXX-B | Specification | 4 (shared) | 28 | - | 28 |
| KBC Model | Download | RJ45-10/100 | RJ45-GB | SFP-100m | SFP-GB | Ports Total | PoE Budget (watts) |
|---|---|---|---|---|---|---|---|
| ESUGS2-G1-B | Specification | - | 2 PoE + 1 | - | 3 | 60 up to 30 watts max per RJ45 port | |
| ESUGH2-G1-L-B | Specification | - | 2 PoE + 1 | - | - | 3 | 180 @ >18VDC up to 90 watts max per RJ45 port |
| ESULS4-M1-B | Specification | 4 | - | 1 | - | 5 | 120 up to 30 watts max per RJ45 port |
| ESULS4-L1-B | Specification | 4 PoE + 1 | - | - | - | 5 | 120 up to 30 watts max per RJ45 port |
| ESUGS4-P1-B | Specification | - | 4 | - | 1 | 5 | 120 up to 30 watts max per RJ45 port |
| ESUGS4-G1-B | Specification | - | 4 PoE + 1 | - | - | 5 | 120 up to 30 watts max per RJ45 port |
| ESUGS4-G1-L-B | Specification | - | 4 PoE + 1 | - | - | 5 | 80 @ >18VDC up to 30 watts max per RJ45 port |
| ESUGS4-P2-B | Specification | - | 4 | - | 2 | 6 | 120 up to 30 watts max per RJ45 port |
| ESUGH4-P2-B | Specification | - | 4 | - | 2 | 6 | 360 @ 57 VDC up to 90 watts max per RJ45 port |
| ESUGS6-P1-L-B | Specification | - | 6 | - | 1 | 7 | 120 @ 12 VDC 160 @ 24 VDC up to 30 watts max per RJ45 port |
| ESUGS8-B | Specification | - | 8 | - | - | 8 | 240 up to 30 watts max per RJ45 port |
| ESULS8-P2-B | Specification | 8 | - | - | 2 | 10 | 240 up to 30 watts max per RJ45 port |
| ESUGS8-P2-L-B | Specification | - | 8 | - | 2 | 10 | 120 @ 12 VDC 160 @ 24 VDC up to 30 watts max per RJ45 port |
| ESUGS8-P2-B | Specification | - | 8 | 2 | 10 | 240 up to 30 watts max per RJ45 port | |
| ESUGH8-P2-B | Specification | - | 8 | - | 2 | 10 | 500 @ 57 VDC (4) up to 90 watts max per RJ45 port (4) up to 30 watts max per RJ45 port |
| KBC Model | Download | RJ45-10/100 | RJ45-GB | SFP-100m | SFP-GB | Ports Total |
|---|---|---|---|---|---|---|
| ESULN4-M1-B | Specification | 4 | - | 1 | - | 5 |
| ESULN4-L1-B | Specification | 5 | - | - | - | 5 |
| ESUGN4-P1-B | Specification | - | 4 | - | 1 | 5 |
| ESUGN4-P2-B | Specification | - | 4 | - | 2 | 6 |
| ESULN8-P2-B | Specification | 8 | - | - | 2 | 10 |
| ESUGN8-P2-B | Specification | - | 8 | - | 2 | 10 |
| ESUMN8-P2-B | Specification | - | - | 8 | 2 | 10 |
