ESUGH2-G1-L-B

Downloads - Information

ESUGH2-G1-L-B Specification

ESUGH2-G1-L-B

The KBC ESUGH2-G1-L-B is a high performance, unmanaged industrial switch with 3*10/100/1000M auto-sensing copper ports. Two of the copper ports support PoE/PoE+/PoE++, with up to 90W output on each PoE port.

The switch is powered by 9~36 VDC power supply and is ideal for applications where +12VDC or 24VDC power is available. The unique mount design makes DIN mounting and removal easy. Its rugged
design with IP40 and industrial level 3 ESD protection make this switch suitable for use in harsh environments, such as power, transportation, pipeline, petrochemicals, industry automation and IP surveillance.

 Product Features

  • Unmanaged industrial switch.
  • 3×10/100/1000Base-T(X) ports, 2 PoE++ ports, 1 Non-PoE port.
  • Each PoE port output up to 90W.
  • Support IEEE802.3af&at&bt.
  • 9 ~ 36VDC power supply input.
  • Overload current protection and reverse polarity protection.
  • Level 3 ESD protection.
  • IP40 housing design.
  • Supports DIN-rail and wall-mount.
