ESSGS4-G1-L-B
The KBC ESSGS4-G1-L-B is an Industrial Unmanaged Plus, Gigabit Switch with PoE+ designed for critical, space-constrained, and harsh-environment applications. Part of KBC’s next-generation Unmanaged Plus family, the ESSGS4-G1-L-B provides the plug-and play simplicity of an unmanaged switch while adding PowerPilot™ PoE Control—a lightweight web-based GUI that enables users to check PoE usage and requested PoE power, power-cycle, and schedule PoE ports without requiring any advanced network configuration. Built in a compact IP40 metal enclosure with extended operating temperatures and industrial-grade EMC protection, the switch is engineered for reliable operation in transportation, utilities, energy, perimeter security, industrial automation, and remote infrastructure deployments.
- Unmanaged design with PowerPilotTM PoE control
- Web-based GUI interface
- PoE power usage information per port
- PoE port on/off control
- PoE power and Link scheduling (daily/weekly)
- PoE budget display
- 5x 10/100/1000Base-T(x) ports; 4 PoE+ ports and 1x Non-PoE Port
- Each PoE port outputs up to 30W; 120W total PoE budget
- Supports IEEE802.3af&at
- Low voltage input 9~36VDC
- Overload current protection and reverse polarity protection
- Level 3 ESD protection
- Rugged IP40 housing design
- Supports DIN-rail or wall-mount
- Unique DIN mount design makes mounting and removal easy
