ESUGS2-G1-B

The KBC ESUGS2-G1-B is a high performance, unmanaged industrial switch with 3* 10/100/1000M auto sensing copper ports. Two copper ports support PoE/PoE+, with up to 30W output on each PoE port.

Unique mount design makes DIN mount and removal easy. Rugged design with IP40 and industrial level 3 ESD protection makes the switch suitable for harsh environment applications, such as power, transportation, pipeline, petrochemicals, industrial automation and IP surveillance.Unmanaged industrial switch

  • 3×10/100/1000Base-T(X) ports, 2 PoE+ ports
  • Each PoE port output up to 30W
  • Support IEEE802.3af&at
  • Overload current protection and reverse polarity protection
  • Level 3 ESD protection
  • IP40 housing design
  • Support DIN-rail or wall mounted
  • Unique DIN mount design makes mount and removal easy


Typical System configuration for esugh2-g1-l
