ESUGH8-P2-B

The KBC ESUGH8-P2-B Series is a high performance unmanaged industrial gigabit Ethernet switch with 8 x 10/100/1000M auto sensing copper ports and 2 x gigabit SFP ports. Four copper ports support PoE/PoE+ where each port offers a maximum of 30w power per port, four copper ports support PoE/PoE+/PoE++ where each port offers a maximum of 90w power per port. The switch is rugged in design with an IP40 enclosure and industrial level 3 ESD protection. Unique Din mount design makes mounting and removal simple. The rugged design is suitable for use in harsh environment applications such as in Power, Transportation, Pipeline, Petrochemical, Automation Industries and IP surveillance.

• 8 x 10/100/1000Base-T(X) ports
• 2 x gigabit SFP ports
• Four PoE+ ports output up to 30W per port
• Four PoE++ ports output up to 90W per port
• PoE budget of 500W
• Unmanaged industrial switch
• Supporting IEEE802.3af, at and bt
• Overload current protection and reverse polarity protection
• Level 3 ESD protection
• IP-40 housing design
• Supporting DIN-rail or wall mount
• Unique DIN mount design makes mount and remove easy
